Specification
規格
車架
URS Premium Aluminium
• Gravel+ Geometry
• Internal Cable Routing
• Fender and Rack Mounts
• PF86 Bottom Bracket
• Flat Mount Disc • 12x142mm Thru-Axle
• Gravel+ Geometry
• Internal Cable Routing
• Fender and Rack Mounts
• PF86 Bottom Bracket
• Flat Mount Disc • 12x142mm Thru-Axle
管材
URS Premium Aluminium
尺寸
XS / S / M
前叉
URS Carbon
• Internal Brake & Hub Dynamo Cable Routing
• Fender Mounts • Cargo Mounts
• Flat Mount Disc • 12x100mm Thru-Axle
• Internal Brake & Hub Dynamo Cable Routing
• Fender Mounts • Cargo Mounts
• Flat Mount Disc • 12x100mm Thru-Axle
五通規格
PF86
大齒盤
SHIMANO GRX 600 40T
飛輪
SHIMANO SLX 11spd 11-42T
鏈條
SHIMANO 105
前變
-
後變
SHIMANO GRX 800
變把
SHIMANO GRX 800
夾器
SHIMANO GRX 600, SM-RT64 Rotors (160/160)
車把手
BMC RAB 03, Ergo Top Shape, Compact Bend
龍頭
BMC MSM02
坐管
BMC RSP 03
坐墊
Selle Royal
花鼓
CL-712 (F)/RXC-1425 (R), Thru Axle
輪組
PRD23, 23mm
外胎
WTB Riddler, 45mm
顏色
pet-wht-blk
Geometry
幾何
| Size | XS | S | M | ||
| Rider Height cm | <165 | 162-172 | 170-182 | ||
| Stack | 525 | 550 | 580 | ||
| Reach | 390 | 400 | 410 | ||
| Seat Tube (st) | 430 | 445 | 475 | ||
| Top Tube (tt') | 540 | 558 | 576 | ||
| Head Tube (ht) | 92 | 118 | 150 | ||
| Seat Angle (sa) | 74° | 74° | 74° | ||
| Head Angle (ha) | 70° | 70° | 70° | ||
| Rear Center (rc) | 430 | 430 | 430 | ||
| Front Center (fc) | 608 | 626 | 647 | ||
| Wheelbase (wb) | 1028 | 1047 | 1068 | ||
| BB Drop (drop) | 69 | 69 | 69 | ||
| Fork Length (fl) | 410 | 410 | 410 | ||
| Fork Rake (fr) | 45 | 45 | 45 | ||
| Trail | 78 | 78 | 78 | ||
| Crank Length | 170 | 170 | 172.5 | ||
| Stem Length | 70 | 70 | 70 | ||
| Stem Angle˚ | ±6° | ±6° | ±6° | ||
| Bar Width | 420 | 420 | 420 | ||
| Bar Drop | 130 | 130 | 130 | ||
| Bar Reach | 70 | 70 | 70 | ||
| Seatpost Length | 350 | 350 | 350 | ||
| Seatpost Offset | 15 | 15 | 15 | ||
| *原廠保留規格修改權利 |
